Electronics
-
Battery
15Ah 720 Wh Safe Shield Advanced External Battery, Samsung 50GB or LG M50LT cells, UL Certified to UL-2271 -
Class
Class switchable 1 to 3. Ships in Class 2 status. -
Charger
48VDC, 2 Amp Rad Power Bikes smart charger, operates on 100V-240V AC power outlets -
Display
Rad custom color display. See Display section below for details. -
Hub Motor
Rear hub 750W, 90 Nm
Stated wattage is the manufacturer’s rated power capacity. Actual power-to-ground wattage is under 750W to ensure ebike regulatory compliance and may vary depending on riding conditions. -
Lights
Auto-on feature
Front: ~200 lumens LED headlight with built-in reflector
Rear: Integrated taillight with brake light and turn signals -
Pedal Assist
Torque sensor, 5 PAS Levels, plus a zero assist option -
Range
Estimated 20-60 miles per charge -
Throttle
Half twist throttle -
USB Ports
One USB-C port, located on display
To ensure uninterrupted shipping, some parts may differ from those listed. Rest assured, our engineers rigorously test each component to guarantee quality and compatibility.
Components
-
Bell
Yes -
Brake System
Tektro Hydraulic Disc HD-E395 -
Brake Pads
Tektro Semi-Metallic E11.11 -
Brake Rotors
180 mm x 2.3mm -
Crank Set
50T with dual sided chain ring cover, 170mm crank arms -
Derailleur
7-speed Shimano -
Fenders
Full coverage front and rear, plus integrated wheel cover -
Fork
RST Guide suspension fork, 45mm travel, tapered steerer tube, thru axle -
Frame
Aluminum -
Freewheel/Cassette
7-speed freewheel, 11-34T -
Gearing
1x7 speed -
Grips
Ergonomic rubber comfort grips -
Handlebar
Aluminum, 680 mm wide -
Kickstand
Dual leg center stand, spring loaded, steel -
Pedals
Composite platform, CrMo axle with reflectors, standard 9/16" x 20 TPI threading -
Rear Rack
Integrated, 120 lb (54.4 kg) carrying capacity -
Saddle
Padded flat touring saddle with shallow anatomic cut-out, wide contoured sides -
Seatpost
390 mm x 27.2 mm -
Seatpost Clamp
40 mm -
Shifter
Shimano, 7-speed thumb shifter -
Stem
35mm A-head -
Tires
Kenda 20" x 3.3"
To ensure uninterrupted shipping, some parts may differ from those listed. Rest assured, our engineers rigorously test each component to guarantee quality and compatibility.
Geometry
.png?v=1708559022292&options=w_200)
Title | Text |
---|---|
Rider Heights | 4'11"-6'3" (150-190 cm) |
Bike Weight | 86 lb (39 kg), 75.6 lb (34.3 kg) with battery removed |
Payload | 375 lb, 265 lb max rider weight |
Rear Rack Payload | 120 lb (54.4 kg) |
Handlebar Height | 44" (111.8 cm) |
Reach | 14.2" (36 cm) |
Seat Height | From ground: 30.5" - 41.8" (77.5 - 106.1 cm) From pedal bottom stroke: 25" - 37" (64 - 94 cm) |
Stepover Height | 19.8" (50.3 cm) |
Standover Height | 21" (53.3 cm) |
Total Length | 76" (193 cm) |
Wheelbase | 50.7" (128.8 cm) |
Seat Tube Length | 13.5" (34.2 cm) |
Display
-
Class level
Choose speed settings for your ride:
Class 1: up to 20 mph, throttle only works while pedaling.
Class 2: up to 20 mph while pedaling or throttling.
Class 3, Limited: up to 25 mph while pedaling.
Class 3: up to 28 mph while pedaling.
Remember: adhere to posted speed limits and check local regulations for any speed or ebike class restrictions on the road or trail you're using. -
Speedometer
Fast and Curious? The speedometer will tell you your current speed. -
Odometer
Track the distance you’ve racked up, either by trip or through the bike’s entire lifespan. -
Estimated remaining range
Is it time to recharge? To help you keep track, this displays your remaining battery life in either percentage or remaining miles. -
Trip time
Did your trip feel like it was just half an hour, or did time fly by? This display will show you the time you spend on each outing. Be sure to reset your trip odometer before a ride you want to track. -
Pedal assist level
The higher the number, the more the motor will boost you when you pedal. This shows what level you’re on, from 0 to 5. -
Motor watts
Check out how much power the motor is supplying at any given time. -
Headlight, taillight, and rear turn signals
It’s always a bright idea to make sure your lights are on and operating.
Note: Rear turn signals can be manually turned off or will turn off automatically two minutes into use. -
USB charge indicator
Charging your device? This will confirm if your phone (or tablet, or smartwatch, or headphones, or …) is getting the juice it needs.
